| Stock-No. |
1020-21189 |
| Category |
Travelling column milling machine |
| Make |
ZAYER |
| Type |
30KCU 10000AR |
| New in |
2009 |
| Control |
Siemens 840D |
| Location |
ab Werksstandort,unter Strom |
| Origin |
Spain |
| Delivery time |
immediately |
| Freight basis |
Ex Site - factory |
| Price |
| x-travel |
10000 mm |
| y-travel |
3000 mm |
| z-travel |
1600 mm |
| Control |
Siemens 840D |
| milling head -swivable |
360.000 pos |
| milling head |
Universalfräskopf 45° |
| spindle turning speed range |
6000 U/min |
| spindle motor |
47 kW |
| Tools changer |
60 pos. |
| feed |
5000 mm/min |
| Rapid Travel X / Y / Z-Achse |
10 / 15 / 15 m/min |
| total power requirement |
80 kVA |
| weight of the machine ca. |
40 t |
| dimensions of the machine ca. |
m |
| Description |
Travelling-column milling and drilling centre
- Siemens 840D control system
- Automatic tool changer with 60 positions (SK/ISO 50)
- Universal milling head 0.001°
- Chip conveyor
- Coolant and filter system with 1,000-litre tank
- No internal cooling
- Rotary table 2,500 × 2,000 mm 20 tonnes (W-axis: 1,500 mm)
- Second rotary table 4,000 × 25,000 mm
|
