| Stock-No. |
1020-21092 |
| Category |
Vertical Turret Lathe - Double Column |
| Make |
BERTHIEZ |
| Type |
TDM 630 |
| New in |
1978/2010 |
| Control |
Siemens Sinumerik 840D |
| Location |
ab Werksstandort,unter Strom |
| Origin |
France |
| Delivery time |
short-dated |
| Freight basis |
ex foundation "is as is, where is" |
| Price |
| faceplate diameter |
6300 mm |
| swing diameter |
9700 mm |
| turning height |
4900 mm |
| ram head dimension |
360 x 360 mm |
| faceplate turning speed range |
0,4 - 50 U/min |
| workpiece weight |
150 t |
| main drive motor |
71 kW |
| Control |
Siemens Sinumerik 840D |
| total power requirement |
230 kVA |
| weight of the machine ca. |
- t |
| dimensions of the machine ca. |
- m |
| Description |
2010 overhauled and modernised, new electric etc, equipped with:
- Siemens Sinumerik 840D (2 Panels Left/right Side)
- C-axis and milling spindle
- 2 ram support on cross beam
- milling spindle with 1000 rpm, 28kW (right ram)
- Turning support (left ram)
|
