| Stock-No. |
1020-20894 |
| Category |
Roll Grinder |
| Make |
WALDRICH-SIEGEN |
| Type |
WS II A 100/25 x 5000 |
| New in |
1962/1996 |
| Control |
-- |
| Location |
ab Lager - demontiert |
| Origin |
Germany |
| Delivery time |
immediately |
| Freight basis |
EXW |
| Price |
| grinding diameter |
1200 mm |
| grinding length |
5000 mm |
| swing diameter |
-- mm |
| roll diameter |
1000 mm |
| workpiece weight |
25.000 kg |
| grinding wheel size |
900 x 90-125 x 305 mm |
| grinding wheel turining speeds |
320 - 1600 U/min |
| grinding motor |
97,6 kW |
| cutting speed |
40 m/s |
| workpiece spindle head: |
|
| workpiece-spindlehead motor |
40,5 kW |
| centre height |
700 mm |
| work piece spindle speed |
6 - 60 U/min |
| Control |
-- |
| total power requirement |
138 kW |
| weight of the machine ca. |
52 t |
| dimensions of the machine ca. |
12,5 x 4,3 x 2,0 m |
| Description |
General overhaul in 1996
- Machine without electrical system and control system (machine is in very good
mechanical condition. Electrical system and control system must be replaced)
- Movable grinding carriage
- 2 mounting support steady rests
- Coolant system
- Tailstock
- Hollow and crown grinding device
- One-piece upper support
- Grinding spindle balancing device
- Automatic grinding wheel retraction when power is switched off
- Measuring retraction and repositioning of the grinding wheel
with an accuracy of 0.001 mm with display
- 1 grinding wheel dressing device
|
|
|
|
